PRODUCT HIGHLIGHTS
- Product ConditionNew and Factory Fresh
- Limited Warranty2 Year
- Shipping Weight175 lbs.
- 3U Rack/Tower
- 4.50 Hour Recharge
- 12 Minute Stand-by
- 110 V AC, 220 V AC Input
- 120 V AC Output
- Serial Port
- USB
- 4 x NEMA 5-15/20R, 4 x NEMA 5-15R
- TAA Compliant
Tripp Lite by Eaton UPS TAA SmartPro 120V 2.2kVA 1.92kW Line-Interactive Sine Wave UPS 3U 120/230V input Network Card Options USB DB9
PRODUCT HIGHLIGHTS
- Product ConditionNew and Factory Fresh
- Limited Warranty2 Year
- Shipping Weight175 lbs.
- 3U Rack/Tower
- 4.50 Hour Recharge
- 12 Minute Stand-by
- 110 V AC, 220 V AC Input
- 120 V AC Output
- Serial Port
- USB
- 4 x NEMA 5-15/20R, 4 x NEMA 5-15R
- TAA Compliant
OVERVIEW
Tripp Lite by Eaton UPS TAA SmartPro 120V 2.2kVA 1.92kW Line-Interactive Sine Wave UPS 3U 120/230V input Network Card Options USB DB9

Tripp Lite's dual input voltage SM2200RMDVTAA line interactive UPS system maintains 120V nominal output when powered by North American 120V or International 230V input. 3U rack / tower form factor with an installed depth of only 22.5 inches. Expandable battery runtime with optional BP48V24-2U and BP48V60RT3U external battery packs. Includes C20 power inlet with set of 4 international cordsets and both NEMA 5-15R and 5-15/20R output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Integrated 2-bank programmable PDU switching supports load shedding and remote-reboot of up to 2 individual connected devices. 3-stage metered current monitoring and battery charge status LEDs. 95% efficiency in line power mode. More from the Manufacturer
PACKAGE CONTENTS
- SmartPro SM2200RMDVTAA 2200 VA Tower/Rack Mountable UPS
- 5 x International Input Power Cables
- USB Cable
- Serial Cable
- EPO Cable
- PowerAlert Software CD
- Tower Stand Kit
- 4 Post 19 inch Rackmount Mounting Kit
- 2 Post 19 inch Rackmount Mounting Kit
- User Manual
